Unicab/ Unimat Underfloor Heating Mat/Cable

Unicab/ Unimat Underfloor Heating Mat/Cable

A niche series of electric heating cables/ heating mats was developed more than five years ago which has attractive features over the conventional heating cables and mats.

It is a sleeveless construction or you can say jointless version. In Unicab/ Unimat heating cable/ heating mat there is no sleeve/ connection between Hot – Cold junction.

It is 100% water tight.
It is connector-free.
It is a continuous heating cable.
It is available in all wattage range and densities.
It is highly reliable.
IP 68 Protection rating.
It can be designed as bespoke requirements.



Product Range Model: UM

Under floor heating Mat:200W/m²
Product CodeArea (m²)Wattage (W)Resistance (Ω)
UM-91200080011200264.5
UM-91200080151.5300176.33
UM-91200080022400132.25
UM-91200080252.5500105.8
UM-9120008003360088.16
UM-91200080353.570075.57
UM-9120008004480066.13
UM-91200080454.590058.8
UM-91200080055100052.9
UM-91200080066120044.08
UM-91200080077140037.78
UM-91200080088160033.06
UM-91200080099180029.4
UM-912000801010200026.45
UM-912000801111220024.05
UM-912000801212240022.05
